This 12’ wide by 16’ deep king post plan has a 12/12 roof pitch and generous 24” overhangs. A fun beginner timber framing project, this could be used for a playhouse for the kids, a garden shed, or a tiny camping cabin. This attractive frame is constructed with sturdy 8×8 timbers.
The design includes a timbered floor system as an option. With this versatile plan, you could shorten or lengthen the purlins to adjust the depth, make the posts taller, and add some joists to include a loft.
The drawings include an instant 23-page PDF download, with individual piece drawings and a full timber list.
