Timber Frame Shed Roof Plan

$97.00

SKU: 4923 Categories: , Tag:

This shed roof will add a touch of timber framing to your life – whether you use it to expand your outdoor living space as a new porch or you offer it as an elegant lean-to shed for your horses or livestock. If you connect it to your home, you can easily screen it for an elegant space in which to entertain friends and neighbors (but not bugs). Or, bring your horses home with the knowledge you can offer them stalls and have room for storage by adding partitions after enclosing the structure on three sides.

  • Can be used as an addition to a shed, barn or added to a front or rear of a home and used as a screened or covered porch.
  • 10' wide x 36' long shed roof, can easily be modified in the field for different lengths.
  • Also included are 8', 9', 11', 12' 13' and 14' deep variations in a separate PDF so you can choose the best depth for your project.
  • Instantly downloadable PDF drawings include 18 pages full of plan views, elevations section drawings and individual piece drawings, plus a second PDF with 8 additional sheets.
  • Full timber list
  • 3D renderings including x-ray views to show you all the details to help you visualize the frame
  • 3 inch roof pitch (14.04°)
  • Great DIY project that will add valuable space to your homestead.

This plan is also included in the Master Plan Bundle and the Timber Frame Porch Plan Bundle.

10x36 Plan Overview

Frequently Asked Questions

Do you offer the whole kit?

Yes we do! Just fill out the form HERE and will will be in touch soon with more information and pricing.

Can  you modify this plan for me?

Yes, we can modify our plans to the size you need on a custom basis. For more information on the services that we offer and how the process works check out the page HERE

 If that is something that would interest you, fill out the  brief questionnaire HERE or click Get Started Today on the main Design Page from above.

As soon as we get your information and give it a quick review we’ll contact you to schedule a phone meeting.  Please allow a few days for our team to respond.

Before our discussion, we urge you to buy the set of plans that most resembles the alteration that you seek. This will allow you to study the plans thoroughly, think through any other changes or design aspects that you want.

Are your plans engineered?

The plans we offer on our website are not stamped by an engineer. People build our frames all over the country, and in each location, there are different requirements.  Timber species, design loads and values needed are just some of the factors engineers need to take into account in each case.

We do offer engineering services as an add-on to our standard plans. If this is something you are interested in, head HERE and fill out the brief questionnaire.  Armed with that information, we can get our heads into your project before we speak.  That way we are best prepared to answer all of your questions.

As soon as we get your information and give it a quick review we’ll contact you to schedule a meeting.

Have a question for us?

100% Money Back Guarantee for 30-Days

Purchase With Confidence...It's Risk Free!

If, for any reason, you don't like this plan, you can get a full refund anytime within 30 days after your purchase. If you have any issues, just get in touch with our support team and they'll either help you out until you get the results you need or give you a swift refund.
