16×24 Timber Frame Carport

This 16×24 carport has some great features! The rafters and purlins create a fabulous rhythm in the roof structure, which has a commanding presence with a 12-in-12 pitch. And the gently curved knee braces and truss struts are beautiful. You’ll be proud to show off this timber frame to your family and friends when the work is done!

You could use this 384 square-foot frame for many different things – a timber frame carport, backyard workshop, guest house or even a Porte-cochere for your entrance! The only limit to how to enjoy this 16×24 pavilion with purlins is your imagination. Leave the structure open for an outdoor living space, or add roofing, siding, doors, and windows as you see fit.

The drawings are formatted to 8 1/2″x 11″, and you can download the PDF the instant you purchase. The 25-page set includes a plan, section, elevations, detail drawings, and three-dimensional renderings so you can picture the result. We also include a timber list to determine your budget and acquire your timber easily.

Check out this plan in our shop: 16×24 Heavy Timber Pavilion Plan.
