This versatile small timber frame plan could be finished as a workshop or a glamping cabin. It measures 12’ wide by 36’ deep and has three bays. The loft expands your living or storage space. Add our 10x36 shed plan, and you will have a cool little cabin. Too long? Easily adjust the length to match your needs.
Please note that, unlike most of our plans, this frame is designed as rough-sawn. The piece drawings are shown dimensioned at the actual size of 8x8
The instant-download PDF drawings include 26 sheets, including renderings, timber schedule, plan, elevation, and sectional drawings, and all the piece and joinery details you will need to build this small timber frame. Formatted in an instantly downloadable PDF for 8 ½” x 11’ paper.
