40×42 Monitor Barn House Plan

$197.00

SKU: 43615 Categories: , , , Tags: , ,

If you are wanting a sizable structure with great presence and utility, look no further than this 40x42 monitor barn house plan! True to this style of barn, our plan has a large center aisle with shed wings on both sides, and a second level above the center aisle.  We have designed this to fit on a 40x42 foundation after the addition of 5 1/2" Studs, and 5/8" furring strips behind the posts for drywall to be installed.  You can enclose the entire structure, or leave one of the wings open for a comfortable porch.

With this package, we include architectural plans fleshed out as a four bedroom home with vaulted ceilings, large kitchen and living areas, and even a mud room!

  • Outside to outside of the posts measures 38’-11 ¾” x 40’-11 ¾”
  • With cladding, square footage is approx. 1680 first floor and 650 second level
  • Roof pitches 8:12 center aisle, 4:12 shed wings
  • Height to top of center rafters: 24’-10”; height to top of shed rafters: 13’-3”
  • Height to top of center plates: 19’-7”; height to top of shed plates: 9’-6”
  • Plan utilizes 9009.3 board feet
  • Mortise & tenon, spline and scarf joinery

As soon as you purchase this plan you will receive links to download the PDFs. The construction set contains 13 pages of detailed information. There are 3D drawings so you can visualize the finished frame, including a production drawing with every timber labeled. There are post, loft and roof plans, elevations and section drawings. And there are plenty of notated detail drawings explaining the complexities.  The piece drawing set contains 47 pages, showing you all the information you need to make the cuts on every timer. And we include connector, parts and timber lists to make procuring your materials easier.
