Take a look at this 18×24 king post timber frame plan. This plan would work well as a small guest house or carport, or an expansive workshop. The generous size of this design would also make a great outdoor kitchen and dining pavilion. The top of the plates are over nine feet high, and at a 6 in 12 pitch the ridge stands at well over 14 feet tall for a lofty ceiling height. If you want to customize the look of the pavilion, we include roof pitch drawings from 3/12 all the way to 12/12, so take your pick!
- 432 square feet under roof
- Generous two-foot overhangs
- Two-bay design
- Gable ends to utilize two different post layouts for flexibility.
- Sturdy 8x post construction
The instant-download PDF drawings consist of 33 sheets, which includes 3D renderings, plan, elevation, and sectional drawings, along with all the piece and joinery details you will need to build this frame. Every cut on every timber is dimensioned out for you, so there is no guesswork. We include a timber list and fastener schedule to make gathering your materials easier. The plan set is formatted for easy printing at home on 8-½” x 11” paper.
Frequently Asked Questions
Yes, we can modify our plans to the size you need on a custom basis. For more information on the services that we offer and how the process works check out the page HERE.
If that is something that would interest you, fill out the brief questionnaire HERE or click Get Started Today on the main Design Page from above.
As soon as we get your information and give it a quick review we’ll contact you to schedule a phone meeting. Please allow a few days for our team to respond.
Before our discussion, we urge you to buy the set of plans that most resembles the alteration that you seek. This will allow you to study the plans thoroughly, think through any other changes or design aspects that you want.
The plans we offer on our website are not stamped by an engineer. People build our frames all over the country, and in each location, there are different requirements. Timber species, design loads and values needed are just some of the factors engineers need to take into account in each case.
We do offer engineering services as an add-on to our standard plans. If this is something you are interested in, head HERE and fill out the brief questionnaire. Armed with that information, we can get our heads into your project before we speak. That way we are best prepared to answer all of your questions.
As soon as we get your information and give it a quick review we’ll contact you to schedule a meeting.
Yes we do! Just fill out the form HERE and will will be in touch soon with more information and pricing.
100% Money Back Guarantee for 30-Days
Purchase With Confidence...It's Risk Free!
If, for any reason, you don't like this plan, you can get a full refund anytime within 30 days after your purchase. If you have any issues, just get in touch with our support team and they'll either help you out until you get the results you need or give you a swift refund.
