Looking for timber frame plans that balance compact design with exceptional strength? These 16x24 Timber Frame Pavilion Plans are ideal for creating a backyard pavilion, carport, outdoor studio, or guest retreat. The structure’s rafter-based roof system makes the build straightforward—perfect for experienced DIYers or timber framing enthusiasts.
Once your posts and eave plates are set, you can assemble the king post trusses on the ground and lift them into place. Then connect the ridge, rafters, and curved braces—and your frame is complete.
Frame Details:
- Dimensions: 16' x 24' (outside of 8x8 posts)
- Peak Height: ~17 feet at ridge; just over 10 feet at eaves
- Design Features:
- King post trusses with curved braces and struts
- Scarf joints on plates allow shorter timbers
- Reinforced with structural screws (fasteners available via Timber Frame HQ)
What’s Included in the Plans:
- Complete Construction Documents
- Five 11x17 sheets with plan views, sections, elevations, and 3D diagrams
- A 19-page set of detailed piece drawings—showing every cut
- Full timber list and connector list for easy sourcing and prep
These 16x24 pavilion plans make it easy to create a compact yet visually impressive timber frame structure that works in a variety of applications—open or enclosed.
