12×12 Timber Frame Plan

12x12 Timber Frame Shed

This 12×12 timber frame plan is extremely versatile because it can be used to build a porch, shed, or pergola over a hot tub.  It is a simple timber frame to cut and raise by hand. However, it will still offer you a challenge in some of the joinery details, making it a great DIY project.  Cover it with 1 1/2″ tongue and groove, and you are ready to put a roof on it.

The plans are formatted in PDF and available for instant download.  With a total of 23 pages on 8.5″x11″ pdf sheets, including 3d renderings, timber schedule, plan, elevation, and sectional drawings along with all the piece and joinery details you will need to build this small timber frame.

Check out this plan in our shop here: 12×12 Timber Frame.

12x12 Plan Overview
