Are you looking for a small structure to get started in timber framing? Do you want to adorn a small backyard space? This petite 10×14 king post pavilion may be just the plan for you! You can use it for a hot tub shelter, storage shed, or playhouse; however, it has a nice small footprint. Its small size makes it easy to cut and raise, yet you can show off your joinery skills with the mortise and tenon work. This structure has a 12-inch (45-degree) roof pitch, which makes a nice ceiling height in a small space.
When you download the 21-page plan set, you will receive detailed drawings of the 10×14 king post pavilion, including plan views, elevations, and section drawings. We include individual piece drawings which show each cut on every timber. We also include a full timber list to make budgeting and purchasing your lumber easier. You will also receive 3d renderings, including x-ray views, to show you all the details you need to help you visualize the frame.
