The 14x28 Winged Shed Pavilion is a truly distinctive timber frame—blending bold architectural style with complex craftsmanship. With its bandshell-inspired design, soaring rooflines, and dynamic geometry, this frame will stand as a centerpiece structure in any setting.
Note: This is not a first-time timber framing project. It’s designed for experienced builders ready for a rewarding, ambitious build.
Frame Highlights:
- Total Area: 678 sq ft
- Two 294 sq ft bays joined by a 90 sq ft triangular dormer bay
- Ceiling Heights: 10’ 9” to 17’ 5”
- Roof Pitches:
- Shed roofs: 6:12, rising to over 19’
- Dormer: 12:12
- Overhangs: Generous 2 ½ to 3-foot overhangs with awnings for added style and weather protection
Craftsmanship Features:
- Complex, intersecting roof geometry for experienced framers
- Precision joinery including angled plates and dormer framing
- Designed to become a long-lasting showpiece of your timber framing skills
Build Options:
- Ready-to-Raise™ Kit: Pre-cut, labeled timbers delivered with fasteners and fully engineered construction drawings for a precise and efficient build.
- Plans Only: Comprehensive construction drawings for skilled builders sourcing their own materials.
- Custom Design Services: Want to modify the footprint, roof pitches, or add specialized features? Our design team can tailor this pavilion to match your exact vision.
The angled shed roofs not only create a dramatic silhouette but also provide an excellent opportunity to install solar panels for sustainable energy use.
For experienced timber framers ready to showcase their craftsmanship, the 14x28 Winged Shed Pavilion is Ready-to-Raise™ and ready to become your next signature project.
Buy This Plan
This plan provides detailed, easy-to-follow blueprints, perfect for anyone building their own timber frame.
Customize or Kit
Do you like this plan but need to change it a little, or do you want a complete Ready-To-Raise Kit?
Get An Instant Quote
Use our online calculator to get a quote for a complete Ready-To-Raise Kit. Just need your zip code.
View Our Interactive 3d Model
We understand that every project is unique, so we offer extensive customization options for our plans and kits. Choose from various sizes, roof styles, and finishes to match your style and landscape. Our design team is dedicated to helping you create the perfect plan that reflects your vision.
Here's How You Can Get Started:
- Phone: Call us at 888-552-9379 (9–5, M–F) to speak with one of our experts.
- Email: Send your questions to projects@timberframehq.com, and we will respond within two business days
- Online Form: Please complete the form below, and we will respond promptly.
Hi. My city has. Structure height limitations of 12 feet. Can these plans be modified with a lower roof pitch?
Hi. My city has. Structure height limitations of 12 feet. Can these plans be modified with a lower roof pitch?
Could I get the timber list for this plan so I can see if it is feasible for me. Thanks,
Simon
We do not send out the timber lists, but they are included when you purchase the plans. Keep in mind that we offer a 30-day satisfaction guarantee. If you purchase the plans and can not use them for any reason we refund your total purchase price if you notify us within 30 days of your purchase.
So you know, the 14×28 Shed and Dormer Pavilion requires 4801.7 total board feet.
